Vehicle mounted Drain Cleaning System

View the full image

Vehicle Mounted Drain Cleaning System

Type: Product

IPR Status: Patent

Secured In: India

Application/uses:

The CSIR-CMERI developed machine is designed for up to 5,000 people density i.e. best suitable up to 300 mm diameter and up to a 100-metre length of the sewer system.

It is used to handle the blockage caused by plastic and other non-biodegradable domestic thrown-away items, debris, intrusion of tree roots, etc.

Salient Technical Competing Features:

High Pressure Jetting System with recycled water
Equipped With Safety Operator feedback system
Post Cleaning Inspection camera system (self-propelled type)
Disinfectant System for jetting hose disinfection.
Appropriate filtration and Re-utilization of drain Slurry for jetting
Indigenous, cost effective & Reliable machine
Developed in BS VI chassis (Green and Clean India)

Status of Commercialization: Technology has been transferred to one MSME client M/s MANIAR & CO., Ahmedabad, Gujarat

Major Raw Materials To Be Utilized : Chassis, Slurry Dispensing Unit, Jetting Unit, Post Cleaning Inspection camera system, Safety Operator feedback system, Hoses, Waste Bucket etc

Techno Economic: Available on Enquiry Basis Manufacturing cost : Rs. 7.0 Lakh (approx.) Return of Investment : Less than one year

Technology Package: Complete Manufacturing Drawings & Technology Knowhow with Operation Manual, List of Bought Out Materials

Content Details:

Vehicle mounted Drain Cleaning System consisting of three (03) modules namely Recycled Slurry Water Unit, Closed Loop Feedback System & Post Cleaning Inspection System.

Level/Scale of Development: It was successfully demonstrated at the premises of the National Physical Laboratory, Delhi on 27.10.2021

TRL:

TRL 8
